SATA, eSATA, and eSATAp: Key Differences Explained

sata
esata
esatap
storage interfaces
data transfer

This article breaks down the distinctions between SATA, eSATA, and eSATAp interfaces, highlighting their key differences in speed, power, and application.

SATA (Serial ATA)

  • Full form: Serial ATA
  • Raw data rate: Up to 16 Gbps (Version 3.2)
  • Max. Cable length: 1 meter
  • Power provided: No, SATA does not provide power through the interface itself. Devices require a separate power connection.
  • Devices per channel: 1
  • Use Case: SATA is primarily used for internal connections within a computer, like connecting hard drives, SSDs, and optical drives to the motherboard.

eSATA (External Serial ATA)

  • Full form: External Serial ATA
  • Raw data rate: Up to 6 Gbps
  • Max. Cable length: 2 meters
  • Power provided: No, similar to SATA, eSATA does not supply power. Devices require external power.
  • Devices per channel: 1
  • Use Case: eSATA is designed for connecting external storage devices to a computer, offering a fast data transfer rate compared to USB in many cases.

eSATAp (External Serial ATA with power)

  • Full form: External Serial ATA with power
  • Raw data rate: Up to 3 Gbps
  • Max. Cable length: 1 meter (with passive adapter)
  • Power provided: Yes, eSATAp provides power, typically using a combination of USB for 5V power and optionally 12V through the connector.
  • Devices per channel: 1
  • Use Case: eSATAp combines the data transfer capability of eSATA with the power delivery feature, simplifying connections for external storage devices by eliminating the need for a separate power adapter.

Summary Table

FeatureSATAeSATAeSATAp
Full formSerial ATAExternal Serial ATAExternal Serial ATA with power
Raw data rate16 Gbps6 Gbps3 Gbps
Max. Cable length1 meter2 meter1 meter (with passive adapter)
Power providedNoNoYes (Utilizes USB for 5V and optional 12V)
Devices per channel111

Further Reading

For more information on SATA technology, you might find it helpful to explore the differences between IDE and SATA.
